Bulk Storage Lockers by Hallowell - Bulk Storage Locking ventilated lockers

details

Bulk Storage Lockers- Details

Bulk Storage Lockers

W	D	H	Dark Gray part #	lbs.	Dark Gray part #	lbs.
Starter Units					Adder Units
Single Tier
36	36	90	BSL363690-1S-HG	119	BSL363690-1A-HG	88
36	48	90	BSL364890-1S-HG	133	BSL364890-1A-HG	98
36	60	90	BSL366090-1S-HG	145	BSL366090-1A-HG	102
48	36	90	BSL483690-1S-HG	129	BSL483690-1A-HG	98
48	48	90	BSL484890-1S-HG	143	BSL484890-1A-HG	105
48	60	90	BSL486090-1S-HG	157	BSL486090-1A-HG	112
Double Tier
36	36	45	BSL363690-2S-HG	127	BSL363690-2A-HG	105
36	48	45	BSL364890-2S-HG	155	BSL364890-2A-HG	116
36	60	45	BSL366090-2S-HG	178	BSL366090-2A-HG	127
48	36	45	BSL483690-2S-HG	137	BSL483690-2A-HG	115
48	48	45	BSL484890-2S-HG	165	BSL484890-2A-HG	126
48	60	45	BSL486090-2S-HG	188	BSL486090-2A-HG	137
Accessories for Bulk Storage lockers
Top Panels
36	36	-	4803636HG	9
36	48	-	4803648HG	10	Units available right-hand or left-hand hinged single tier: overall height 90" opening height 75 1/2" Double tier: overall height 90" upper opening height 31 1/2" lower opening height 42" Custom sizes are also available Color: Dark Gray [HG]
36	60	-	4803660HG	11
48	36	-	4804836HG	12
48	48	-	4804848HG	13
48	60	-	4804860HG	14
Front Extension Panels
6	-	90	4600690HG	20
12	-	90	4601290HG	23
18	-	90	4601890HG	26
24	-	90	4602490HG	29
Back Panels
36	-	90	4703690HG	30
48	-	90	4704890HG	38
Repair Angles
36	-	-	20100	3

The Heavy-Duty 7 knuckle hinges and door stops are welded to the frame for extra strength and security of contents, imparting a more finished and attractive appearance to the unit.	Optional 16 gauge 1/2" expanded metal top makes for a very secure structure adding rigidity and ensuring a higher level of protection from theft	Door handles are formed from one solid piece of steel and are welded to the frame for extra strength.
